GROUTING AND WATER CONTROL PACKERS (GWC) are designed for use in underground drill holes for grouting and water control. Packer is usually set by hand, large sizes can be used as stem pipes or drill collars for drilling smaller size holes, ie: the NGWC (76mm) packer can be used as a collar pipe for drilling 46mm holes.

Packers are set by connecting required length of pipe (with open valve attached) and inserting to required depth. Pulling back on pipe and closing valve will set the packer.

Packers are available for all diamond drill, long hole, some large drill steel sizes and rotary percussion holes in a range of from 32mm to 152mm.

Grouting and Water Control Packers can also be supplied blanked off (solid bore)

Construction:
Aluminium and Rubber (sizes 0-96mm)
Aluminium, Steel and Rubber (sizes 108mm and above)

Download Info & Instructions for Use

43,46,48,51

1" BSP

MALE

56,58,60,63,64,66

1-1/4" BSP

MALE

70

1-1/2" BSP

MALE

76

2" BSP

MALE

89,96,100,104

2-1/2" BSP

MALE

108,110,115,122,125

3" BSP

MALE

130,133,135,140

3" BSP

FEMALE

146,150,152,156

4" BSP

MALE
